- Place of Origin: China
- Brand Name: QUANSHUN
- Model Number: Z644TC-16C
Features
The sealing surface of the valve is made of toughened ceramics with abrasion resistance and long service life.
Two-side sealing can realized due to double plate structure of the pneumatic ceramic double disc gate valve.
In the process of opening and closing ,the valve plate can rotate automatically ,which leads to the grinding and polishing between the two sealing surface of the ceramic double plate gate valve.
There is a residue outlet designed for ceramic double disc gate valve, being used to conduct dust blowing periodically .
- Place of Origin: China
- Brand Name: QUANSHUN
- Model Number: Z644TC-16C
Technical Parameters
Size : 2”~12” DN50~DN300
Pressure: Class 150 PN1.0-PN1.6MPa
Body material : WCB(A105,CF8(304),etc.
Sealing Material :Toughened engineering ceramic
Connection Type :Flange type
Drive method: Pneumatic
